static std::list<std::tuple<String, OpType, Node* (*)(Context&)>> Operators = {
{"for", OpType::Word, [](Context& c) {
c.ptr += 3;
c.ptr = ReadUntilNonWhite(c.ptr);
if (*c.ptr == '(') {
c.ptr++;
bool succ = false;
String params = CopyUntilWithinScopeWithLimit(c.ptr, ')', c.end, '(', ')', &succ);
if (!succ) {
error("Invalid 'for' statement", &c);
return (Node*)nullptr;
}
auto s = split(params, ';');
if (s.size() != 3) {
error("Invalid for loop declaration", &c);
return (Node*)nullptr;
}
ForNode* next = new ForNode();
c.loopScope = c.scope;
c.scope = new Scope(c.scope, c.topLevel);
c.scope->parent = c.loopScope;
c.loopScope->childs.push_back(c.scope);
c.loopNode = next;
next->begin = ParseArea(c, s[0].c_str(), s[0].c_str() + s[0].size());
next->test = ParseArea(c, s[1].c_str(), s[1].c_str() + s[1].size());
next->end = ParseArea(c, s[2].c_str(), s[2].c_str() + s[2].size());
Node* rest = ParseArea(c, c.ptr + 1, c.end);
if (rest) {
*c.currentNode = next;
c.currentNode = &(*c.currentNode)->next;
return rest;
}
return (Node*)next;
}
error("No statement found", &c);
return (Node*)nullptr;
}},
{"if", OpType::Word, [](Context& c) {
c.ptr += 2;
c.ptr = ReadUntilNonWhite(c.ptr);
if (*c.ptr == '(') {
c.ptr++;
bool succ = false;
const char* end = ReadUntilWithinScopeWithLimit(c.ptr, ')', c.end, '(', ')', &succ);
if (!succ) {
error("Invalid if statement", &c);
return (Node*)nullptr;
}
IfNode* next = new IfNode();
next->child = ParseArea(c, c.ptr, end);
Node* rest = ParseArea(c, end + 1, c.end);
if (rest) {
*c.currentNode = next;
c.currentNode = &(*c.currentNode)->next;
return rest;
}
return (Node*)next;
}
error("No statement found", &c);
return (Node*)nullptr;
}},
{"return", OpType::Word, [](Context& c) {
c.ptr += 7;
Node* next = new ControlNode();
next->child = ParseArea(c, c.ptr, c.end);
return next;
}},
OPERATION(==),
{"!", OpType::Single, [](Context& c) {
Node* rhs = ParseArea(c, c.ptr + 1, c.end);
Node* next = nullptr;
if (auto rhsv(dynamic_cast<ValueNode*>(rhs)); rhsv) {
next = FuncNodes[1]("op", "!", nullptr);
next->SetValue(0, rhsv->value);
delete rhs;
}
else {
next = FuncNodes[1]("op", "!", nullptr);
next->SetChild(0, rhs);
}
return next;
}},
OPERATION(!=),
OPERATION(<=),
OPERATION(>=),
OPERATION(<),
OPERATION(>),
COPERATION(*=),
COPERATION(/=),
COPERATION(+=),
COPERATION(-=),
{"=", OpType::Two, [](Context& c) {
Node* lhs = ParseArea(c, c.begin, c.ptr);
auto var(dynamic_cast<VariableNode*>(lhs));
if (var == nullptr) {
error("Invalid operand in assignment", &c);
return (Node*)nullptr;
}
if (var->value->type > 0 && var->value->init)
{
error("Trying to assing to constant", &c);
return (Node*)nullptr;
}
if (var->value->type == 2) {
Node* rhs = ParseArea(c, c.ptr + 1, c.end);
auto rhsv = dynamic_cast<ValueNode*>(rhs);
if (rhsv) {
var->value->init = true;
*var->value->value = rhsv->value;
delete lhs;
delete rhs;
return (Node*)skipNode;
}
error("Trying to assing non-constant expression to static variable", &c);
return (Node*)nullptr;
}
var->value->init = true;
*lhs->GetChild(0) = ParseArea(c, c.ptr + 1, c.end);
return lhs;
}},
OPERATION(+),
OPERATION(-),
OPERATION(*),
OPERATION(/),
{"-", OpType::Single, [](Context& c) {
Node* rhs = ParseArea(c, c.ptr + 1, c.end);
Node* next = nullptr;
if (auto rhsv(dynamic_cast<ValueNode*>(rhs)); rhsv) {
rhsv->value = -rhsv->value;
next = rhs;
}
else {
next = FuncNodes[2]("op", "-", nullptr);
next->SetChild(1, rhs);
}
return next;
}},
{"var", OpType::Word, [](Context& c) {
c.ptr += 4;
String name = ReadWord(c);
if (!name.size()) error("Invalid Variable name: " + name, &c);
Node* next;
c.ptr = ReadUntilNonWhite(c.ptr);
bool isArray = false;
Value* val = nullptr;
if (*c.ptr == '[' && *(c.ptr + 1) == ']') {
val = new Value(EVT::Array, "");
isArray = true;
}
else
val = new Value();
if (c.scope) {
auto it = c.scope->variables.emplace(name, Variable(val, 0, false));
next = new VariableNode(&it.first->second, isArray);
}
else {
auto it = c.topLevel->vars.emplace(name, Variable(val, 0, false));
next = new VariableNode(&it.first->second, isArray);
}
return next;
}},
{"const", OpType::Word, [](Context& c) {
c.ptr += 6;
String name = ReadWord(c);
if (!name.size()) error("Invalid Variable name: " + name, &c);
auto it = c.scope->variables.emplace(name, Variable(new Value(), 1, false));
Node* next = new VariableNode(&it.first->second);
return next;
}},
{"static", OpType::Word, [](Context& c) {
c.ptr += 7;
String name = ReadWord(c);
if (!name.size()) error("Invalid Variable name: " + name, &c);
auto it = c.scope->variables.emplace(name, Variable(new Value(), 2, false));
Node* next = new VariableNode(&it.first->second);
return next;
}},
{"++", OpType::Single, [](Context& c) {
Node* lhs = ParseArea(c, c.begin, c.ptr);
if (auto lhsv(dynamic_cast<VariableNode*>(lhs)); lhsv) {
Node* next = FuncNodes[2]("op", "+", nullptr);
VariableNode* nextVar = new VariableNode(lhsv->value);
next->SetChild(0, nextVar);
next->SetValue(1, 1LL);
lhs->SetChild(0, next);
}
else {
error("Cannot increment values", &c);
delete lhs;
return (Node*)nullptr;
}
return lhs;
}},
{"--", OpType::Single, [](Context& c) {
Node* lhs = ParseArea(c, c.begin, c.ptr);
if (auto lhsv(dynamic_cast<VariableNode*>(lhs)); lhsv) {
Node* next = FuncNodes[2]("op", "-", nullptr);
VariableNode* nextVar = new VariableNode(lhsv->value);
next->SetChild(0, nextVar);
next->SetValue(1, 1LL);
lhs->SetChild(0, next);
}
else {
error("Cannot decrement values", &c);
delete lhs;
return (Node*)nullptr;
}
return lhs;
} },
};
Node* ParseArea(Context& c, const char* const begin, const char* const end)
{
Context l = c;
Node* result = nullptr;
l.ptr = begin;
l.begin = begin;
l.end = end;
for (auto const& [key, alnum, func] : Operators) {
int scope = 0;
l.ptr = end;
switch (alnum)
{
case OpType::Word:
while (--l.ptr >= begin) {
if (*l.ptr == '(') scope++;
if (*l.ptr == ')') scope--;
if (*l.ptr == '{') scope++;
if (*l.ptr == '}') scope--;
if (scope == 0) {
if (!isalnum(*l.ptr)) {
if (*(l.ptr + 1) == *key.c_str() && isEqualWord(key, l.ptr + 1)) {
l.ptr++;
result = func(l);
if (result) break;
l.ptr--;
}
}
else if (l.ptr == begin) {
if (*l.ptr == *key.c_str() && isEqualWord(key, l.ptr)) {
result = func(l);
if (result) break;
}
}
}
}
break;
case OpType::Two:
while (--l.ptr >= begin) {
if (*l.ptr == '(') scope++;
if (*l.ptr == ')') scope--;
if (*l.ptr == '{') scope++;
if (*l.ptr == '}') scope--;
if (scope == 0 && *l.ptr == *key.c_str() && isEqual(key, l.ptr)) {
if (l.ptr == begin || *(l.ptr - 1) == '(' || *(l.ptr - 1) == ')'
|| *(l.ptr - 1) == '{' || *(l.ptr - 1) == '}' || std::isalnum(*(l.ptr - 1))
|| std::isspace(*(l.ptr - 1))) {
const char* p = l.ptr;
if (p != begin) while (isspace(*(--p)));
if (isalnum(*p) || *p == ')' || *p == '"') {
result = func(l);
if (result) break;
}
}
}
}
break;
case OpType::Single:
while (--l.ptr >= begin) {
if (*l.ptr == '(') scope++;
if (*l.ptr == ')') scope--;
if (*l.ptr == '{') scope++;
if (*l.ptr == '}') scope--;
if (scope == 0 && *l.ptr == *key.c_str() && isEqual(key, l.ptr)) {
if (l.ptr == begin || *(l.ptr - 1) == '(' || *(l.ptr - 1) == ')'
|| *(l.ptr - 1) == '{' || *(l.ptr - 1) == '}'
|| std::isspace(*(l.ptr - 1))) {
if (isalnum(*(l.ptr + 1))) {
result = func(l);
if (result) break;
}
}
}
}
break;
}
if (result) break;
}
l.ptr = begin;
bool found = false;
while (!isError() && l.ptr != end && (result == nullptr && !found)) {
l.ptr = ReadUntilNonWhiteWithLimit(l.ptr, end);
l.considerValue = ReadWord(l);
l.ptr = ReadUntilNonWhiteWithLimit(l.ptr, end);
if (l.ptr == l.end && l.considerValue.size() == 0) break;
if (*l.ptr == '.') {
l.ptr++;
l.considerScope = l.considerValue;
l.considerValue = ReadWord(l);
l.ptr = ReadUntilNonWhite(l.ptr);
if (l.ptr == l.end && l.considerValue.size() == 0) break;
}
switch (*l.ptr)
{
case '(':
{
l.ptr++;
if (l.considerValue.size() != 0) {
int param_count = 0;
if (l.considerScope.size() != 0) {
Variable* val = l.scope->FindVar(l.considerScope);
if (val) {
param_count = GetParamCount(l, "variable", l.considerValue);
result = FuncNodes[param_count]("variable", l.considerValue, val);
}
else if (auto it = c.function->params.find(l.considerScope); it != c.function->params.end()) {
param_count = GetParamCount(l, "variable", l.considerValue);
result = FuncNodes[param_count]("variable", l.considerValue, &it->second);
}
else if (auto it = nativeFuncs().find(l.considerScope); it != nativeFuncs().end()) {
param_count = GetParamCount(l, l.considerScope, l.considerValue);
result = FuncNodes[param_count](l.considerScope, l.considerValue, nullptr);
}
else {
error("Cannot find scope " + l.considerScope, &c);
break;
}
}
else {
if (l.topLevel->functions.find(l.considerValue) != l.topLevel->functions.end()) {
param_count = (int)l.topLevel->functions[l.considerValue].params.size();
result = new ScriptFuncNode(l.topLevel, l.considerValue, param_count);
}
else {
param_count = GetParamCount(l, "global", l.considerValue);
result = FuncNodes[param_count]("global", l.considerValue, nullptr);
}
}
const char* aend = ReadUntilWithinScopeWithLimit(l.ptr, ')', end, '(', ')');
std::vector<String> params;
while (l.ptr != aend && *l.ptr != '\0') {
l.ptr = ReadUntilNonWhite(l.ptr);
params.emplace_back(CopyUntilWithinScopeWithLimit(l.ptr, ',', aend, '(', ')'));
l.ptr = ReadUntilNonWhite(l.ptr);
if (*l.ptr == ',') l.ptr++;
}
if (!params.empty()) {
if (params.size() > param_count) warn(("Too many parameters in function call: " + l.considerValue).c_str(), &l);
for (int i = 0; i < params.size() && i < param_count; i++) {
uint off = 0;
l.ptr = params[i].c_str();
result->SetChild(i, ParseArea(l, params[i].c_str(), params[i].c_str() + params[i].size()));
}
}
l.ptr = aend + 1;
l.considerValue = "";
break;
}
else
{
bool success = false;
l.end = ReadUntilWithinScopeWithLimit(l.ptr, ')', end, '(', ')', &success);
if (!success) {
error("Expected ')'", &l);
result = nullptr;
break;
}
result = ParseArea(l, l.ptr, l.end);
break;
}
}
break;
case '"':
{
l.ptr++;
bool succ = false;
result = new ValueNode(EVT::String, CopyUntilWithLimit(l.ptr, '"', end, &succ));
l.ptr++;
if (!succ) error("End of String not found", &c);
break;
}
break;
case '[':
{
l.ptr++;
l.ptr = ReadUntilNonWhite(l.ptr);
bool succ = false;
const char* aend = ReadUntilWithinScopeWithLimit(l.ptr, ']', end, '(', ')', &succ);
if (succ) {
Variable* val = l.scope->FindVar(l.considerValue);
if (val && val->value->type() == EVT::Array) {
Node* index = ParseArea(l, l.ptr, aend);
if (val->type == 2) {
if (ValueNode* n = dynamic_cast<ValueNode*>(index); n) {
result = new ValueNode(n->value);
}
else {
error("Cannot use non-static access with static variables", &l);
delete index;
break;
}
}
else
result = new VariableNode(val, true, index);
}
else
{
if (auto it = c.function->params.find(l.considerValue); it != c.function->params.end()) {
Node* index = ParseArea(l, l.ptr, aend);
result = new VariableNode(&it->second, true, index);
break;
}
error("Unknown array: " + l.considerValue, &c);
break;
}
}
else {
error("No matching token found: ']'", &l);
break;
}
} break;
default:
{
bool isfloat = false;
if (isNumber(l.considerValue, &isfloat)) {
result = new ValueNode(isfloat ? EVT::Float : EVT::Int, l.considerValue);
break;
}
Variable* val = nullptr;
if (l.scope) val = l.scope->FindVar(l.considerValue);
else if (l.topLevel->vars.find(l.considerValue) != l.topLevel->vars.end()) {
val = &l.topLevel->vars.find(l.considerValue)->second;
}
if (val) {
if (val->type == 2)
result = new ValueNode(*val->value);
else {
result = new VariableNode(val);
if (*l.ptr == '&')
result->ref = true;
}
break;
}
else if (l.ptr != end && ispunct(*l.ptr)) {
error((String("Unexpected character found: ") + *l.ptr + ' ').c_str(), &l);
l.ptr++;
break;
}
else {
if (l.considerValue == "true") {
result = new ValueNode(true);
break;
}
else if (l.considerValue == "false") {
result = new ValueNode(false);
break;
}
else
{
if (c.function->params.find(l.considerValue) != c.function->params.end()) {
result = new VariableNode(&c.function->params[l.considerValue]);
break;
}
error("Unknown variable: " + l.considerValue, &c);
break;
}
}
}
break;
}
}
ExitContext(c, l);
return result;
}
void ReadLine(Context& c)
{
Context l = c;
Node** prevScope = nullptr;
l.begin = c.ptr;
l.end = l.begin;
int scope = 0;
while (*l.end != '\0' && *l.end != '\n' && (*l.end != ';' || scope != 0) && l.end != c.end) {
if (*l.end == '#') {
while (*l.end != '\n' && *l.end != '\0') l.end++;
l.begin = l.end;
}
if (*l.end == '(') scope++;
if (*l.end == ')') scope--;
if (*l.end == '{') {
if (l.end != l.begin) {
break;
}
l.scope->childs.push_back(new Scope(l.scope, l.topLevel));
ScopeNode* sn = new ScopeNode();
sn->parent = l.scopeNode;
l.scopeNode = sn;
*c.currentNode = l.scopeNode;
c.currentNode = &(*c.currentNode)->child;
l.scope = l.scope->childs.back();
sn->scope = l.scope;
l.begin = ++l.end;
}
else if (*l.end == '}') {
if (l.end != l.begin) {
break;
}
if (l.scope->parent) {
l.scope = l.scope->parent;
c.currentNode = &l.scopeNode->next;
l.scopeNode = l.scopeNode->parent;
if (l.loopNode) {
l.scope = l.loopScope;
l.loopNode = nullptr;
l.loopScope = nullptr;
}
}
else
{
error("Unexpected character found: }", &c);
break;
}
l.begin++;
}
l.end++;
}
c.ptr = l.end;
Node* n = ParseArea(l, l.begin, l.end);
ExitContext(c, l);
if (n != nullptr) {
if (n != (Node*)skipNode) {
while (*c.currentNode) c.currentNode = &(*c.currentNode)->next;
*c.currentNode = n;
if (n->next != (Node*)returnNode) c.currentNode = &(*c.currentNode)->next;
else {
(*c.currentNode)->next = nullptr;
c.currentNode = nullptr;
}
}
}
if (c.ptr != l.end) {
c.ptr = l.end + 1;
ReadLine(c);
}
ExitContext(c, l);
c.ptr = l.end;
if (*l.end == '\n' || *l.end == ';') c.ptr += 1;
c.row++;
}
int BeginParse(Context& c, const char* data, uint off, uint& end, Node** nodePtr)
{
Context l = c;
l.ptr = data;
int wordLen = 0;
l.currentNode = nodePtr;
while (*l.ptr != '\0' && !isError() && l.ptr != c.end && l.currentNode) {
ReadLine(l);
}
c.ptr = l.ptr;
ExitContext(c, l);
return true;
}
void FindFunctions(const char* data, Script* script)
{
const char* function_end = data;
Context c;
c.topLevel = script;
const char* ptr = data;
int depth = 0;
int functionCount = 0;
while (*ptr != '\0') {
if (*ptr == '\n' || *ptr == ';') c.row++;
if (*ptr == '{') depth++;
if (*ptr == '}') depth--;
if (*ptr == 'd' && depth == 0) {
if (*(ptr + 1) == 'e' && *(ptr + 2) == 'f' && *(ptr + 3) == ' ') {
ptr += 4;
int len = 0;
c.ptr = ptr;
String fun = ReadWord(c);
if (*c.ptr == '(') {
c.ptr++;
ScopeNode* scopeN = new ScopeNode();
script->functions[fun].first = scopeN;
Node** fir = &(scopeN->child);
c.scope = new Scope(nullptr, script);
scopeN->scope = c.scope;
script->functions[fun].scope = c.scope;
c.function = &script->functions[fun];
ptr = ReadUntilWithinScope(ptr, ')');
while (c.ptr != ptr && *c.ptr != '\0') {
c.ptr = ReadUntilNonWhite(c.ptr);
c.function->params[ReadWord(c)] = std::move(Variable(new Value, 0, false));
bool success = false;
c.ptr = ReadUntilWithLimit(c.ptr, ',', ptr, &success);
if (success) c.ptr++;
else break;
}
ptr = ReadUntilWithinScope(ptr, '{') + 1;
uint off = 0;
c.end = ReadUntilWithinScope(ptr, '}');
BeginParse(c, ++ptr, 0, off, fir);
ptr = c.end + 1;
function_end = ptr;
}
else {
error("Invalid function definition", &c);
}
}
}
if (*ptr != '\0')
ptr++;
}
if (script->functions.find("execute") == script->functions.end()) {
ScopeNode* scopeN = new ScopeNode();
script->functions["execute"].first = scopeN;
Node** fir = &(scopeN->child);
c.scope = new Scope(nullptr, script);
scopeN->scope = c.scope;
script->functions["execute"].scope = c.scope;
c.function = &script->functions["execute"];
c.begin = function_end;
c.ptr = function_end;
c.end = ReadUntil(function_end, '\0');
uint off = 0;
BeginParse(c, function_end, 0, off, fir);
}
}
void FindVariables(const char* data, Script* script)
{
if (script->setup) delete script->setup;
script->setup = new ScriptFunction();
const char* ptr = data;
Context c;
c.topLevel = script;
c.currentNode = &(script->setup->first);
while (*ptr != '\0') {
ptr = ReadUntilWithinScope(ptr, 'v');
if (isEqualWord("var", ptr)) {
const char* end = ptr;
while (*end != '\0' && *end != '\n' && *end != ';') end++;
*c.currentNode = ParseArea(c, ptr, end);
c.currentNode = &(*c.currentNode)->next;
}
ptr++;
}
}Portfolio of Ilkka Takala
This site contains most of my projects from recent years. Scroll down to explore a selected collection of works, or click 'Projects' from the top banner to easily view all projects I have worked on
I am a programmer specializing in compilers, rendering pipelines and game engines, with experience on other subjects ranging from embedded systems to Windows desktop tools, and a bit of 3D art in the mix.
Scroll down for more
Ilkka Takala
Engineer Student, Game developer
EMI Language
EMI is an interpreted scripting language for games and other software. It is designed to be embedded into existing projects by exposing native functions to the scripting side. The runtime is fairly performant, being able to run pathfinding algorithms in realtime without compiler optimizations.
Divinus Vanitas
Divinus Vanitas is a multiplayer action fantasy game, where you play the role of a mage trying to piece together the broken world. Play with your friends or alone, master spells, and kill the dragon. Get the game on Steam. Created using Unreal's Gameplay Ability System.
21 Heroes
Collect hundreds of legendary heroes and engage in high risk, high reward card battle games in Battlejack, the only fantasy RPG game with a unique blackjack-inspired card battle system!
Mobile game created in Unity, playable on Android and iOS
Project Eril
The Project Eril aims to create complete game engine using C++ and OpenGL. As of version 0.2, many common features are completed and focus is shifting to creating editors and improving end user experience. Version 0.3 introduced animation controls, scripting, particles and more
Yet another game engine
A small game engine built on top of various SDL-libraries to study different engine architectures and programming patterns. The demo game is a remake of Digger.
Demo Script
Scripting language for Project Eril. Javascript-like syntax, type-less variables and more
DirectX Rendering Test
Small game to showcase some basic DirectX 11 rendering functionality later to be implemented in Project Eril. Created in accordance to requirements in Graphics Programming 2 course at Howest University.
Die or Not
Die or Not is a local 2D PvP game, in which two to four (2-4) players play rounds on the same screen until someone reaches the target score. Players get one bullet at a time and have to control the bullet and the character simultaneously to be the last one standing.
Mage VR
VR Puzzle game demo where the players may freely create and edit their spells and interact with the dynamic environment with many unique elements and reactions. Uses Valve Index controllers for gesture input, which is used for casting different spell combinations.
Tripl3 Game Jam 2022
Teams from three different schools work together for three days to create three different games. Each day the games are rotated between the teams so each team works on one game per day.
Cyber / Perspective
Multiplayer shooter made with Unreal Engine 4 during a game jam in Kajaani. The core concept revolves around the players being able to switch perspectives during the matches to use multitude of abilities
Robber Knights digital version
A online multiplayer strategy game, inspired by the original Robber Knights board game. Currently follows the original game and uses the same textures, but I have plans to finish the game using 3D assets and a modified rule set.
Procedural Environment
Procedural environment created in Unreal Engine 5 using tools created in Houdini. Assets from Quixel Megascans and Unreal Engine Marketplace.
Pillar Fighters
A Multiplayer game created during Kajathon 2021 with Unreal Engine 4. In a team of five we created a small game where the players try to each other down from the pillars using guns and a self learning AI assistant
"One Afternoon" Games
Various small games created during free afternoons to try new things and technologies.
3D Art
Collection of my old 3D art from 2016. All images were created with Blender Cycles, with textures from http://www.textures.com/
Portfolio site
